Steel Tech Lights 150W/120W/100W LED Flood Light – Trunnion Mount – Up to 20,314 Lumens – 120–277V – Selectable CCT – IP65 Outdoor Flood Lighting

Certifications: UL Listed; DLC Listed; IP65 Rated
Warranty: 5-Year Warranty

Product Overview

The Steel Tech Lights 150W/120W/100W LED Flood Light with Trunnion Mount is a powerful commercial and industrial outdoor lighting solution engineered for large-scale area illumination, sports facilities, warehouses, parking lots, security lighting, and building facade applications. Featuring selectable wattage and selectable color temperature technology, this fixture allows users to customize brightness and light appearance directly on-site for maximum project flexibility.

Delivering up to 20,314 lumens, this high-output flood light combines advanced LED efficiency with rugged die-cast aluminum construction to provide dependable long-term performance in demanding outdoor environments.

The adjustable trunnion mount provides secure installation and flexible aiming capability, making this fixture ideal for commercial flood lighting projects requiring precise directional control and wide-area illumination.

Specifications

• Selectable Wattage: 150W / 120W / 100W
• Maximum Lumen Output: 20,314 Lumens
• Voltage: AC120–277V
• Color Temperature: Selectable 3000K / 4000K / 5000K
• Control: 0–10V Dimmable
• Mounting: Adjustable Trunnion Mount
• Beam Distribution: 120°
• IP Rating: IP65
• Operating Temperature: -30°C to +50°C
• Rated Life: 50,000+ Hours

Construction

• Heavy-duty die-cast aluminum housing
• Tempered glass lens
• Corrosion-resistant outdoor finish
• Fully sealed weatherproof construction
• Commercial-grade durability for harsh environments

Features

• Selectable Wattage
• Selectable CCT
• Adjustable trunnion mounting system
• High-output LED performance
• 0–10V dimming compatibility
• Wide-area flood distribution
• Energy-efficient commercial lighting
• Long maintenance-free lifespan

Applications

Sports complexes, warehouses, parking lots, industrial facilities, commercial buildings, loading docks, outdoor security lighting, building facades, roadway lighting, and large-scale area illumination.
